Huawei SUN2000-50KTL-M3 Three Phase Solar Inverter – JSolar
The Huawei SUN2000-50KTL-M3 Three Phase Solar Inverter, an advanced solution tailored for large-scale solar installations. This inverter boasts a substantial 55,000VA power output and is equipped with four independent MPP trackers, optimizing energy conversion even under complex environmental conditions. It achieves an impressive efficiency of up to 98.5% and is fully compatible with module optimizers MERC-1100W-P and MERC-1300W-P, ensuring the maximum possible energy harvest. A variety of communication options are available, including 2G, 3G, 4G, Ethernet (with an optional dongle), RS485, AC & DC-MBUS, facilitating effortless system monitoring and control. Benefit from complimentary system monitoring through FusionSolar, and rest assured with the integrated AC and DC overvoltage protection and PID recovery features that contribute to the system’s durability. The inverter’s intelligent air cooling system and IP66 protection guarantee consistent and reliable performance across all environmental conditions.
Product Specifications
Efficiency | 98.5% |
European Efficiency | 98.0% |
Input Voltage | 11,100 V |
Current Per Mppt | 30a |
Current Per Input | 20a |
Short Circuit Current Per Mppt | 40a |
Start Voltage | 200v |
Mppt Operating Voltage Range | 200v ~ 1,000v |
Rated Input Voltage | 600v |
Number Of Inputs | 8 |
Number Of Mpp Trackers | 4 |
Dimensions (W X H X D) | 25.2 X 20.9 X 10.6 Inch |
Weight (With Mounting Plate) | 49 Kg |
Protection Degree | Ip 66 |
